M11-C320
Original Cummins, new machines at absolute wholesale prices.
HekoPower Group is the reliable choice.
Our partner Cummins, a global power solutions leader, comprises five business segments – Components, Engine, Distribution, Power Systems and Accelera by Cummins – supported by Cummins global manufacturing and extensive service and support network, skilled workforce and vast technological expertise. In 1981, Chongqing Engine Plant started to license-produce Cummins engines, and in 1995, it jointly established a Chinese joint venture engine factory with Cummins.
The Cummins M11-C320 is a 10.8-litre, 6-cylinder in-line turbocharged diesel engine, producing 320 HP (235 kW) at 2,000 RPM and a peak torque of 1,234 Nm at 1,300 RPM. This product is used in a variety of industries, including construction, agriculture, and mining. It is employed in a range of equipment, such as Dongfeng trucks, excavators, and cranes. The engine features a fuel consumption of 64.4 L/hr at rated power, an idle speed of 675-750 RPM, and is able to function at altitudes of up to 3,048 metres. With a compression ratio of 16.1:1, a direct injection fuel system, and water cooling, it provides efficient performance across a range of demanding applications.
Specs - Technical standard
General Engine Data
Engine Model: Cummins M11-C320
Type: 6 Cylinders in Line
Displacement: 10.8 L
Bore * Stroke: 125 * 147
Overall Dimension: 1450mm*950mm*1010mm
Net Weight (with flywheel & alternator): 980 Kg
Key Performance Date
Rated Power: 235 kW/320HP
Rated Speed: 2000 rpm
Max Torque/Speed: 1234 N.m @ 1300 rpm
Max. No-Load Speed: 2450 rpm
Fuel Consumption @ Rated Power: 64.4 L/hr
Idle Speed: 675-750 rpm
Max. Continuous Running Altitude: 3048 m
More Technical Data
Certification: Tier 1
Aspiration: Turbocharged-Intercooled
Fuel System: Direct Injection PT Pump, STC
Compression Ratio: 16.1:1
Electrical System (Starter Motor/Alternator): 12V/24V
Lowest Starting Temp Without auxiliary system: -12℃
Cooling Method: Water cooled
Engine Cooling Fluid Volume: 12.9 L
Cummins M11-C Series
Cummins M11-C Series, original products from Chongqing Cummins Engine Plant(CCEC). This series mainly includes M11-C225, M11-C245, M11-C250, M11-C265, M11-C270, M11-C275, M11-C280, M11-C290, M11-C300, M11-C310, M11-C315, M11-C320, M11-C330, M11-C335, M11-C350.
