  • Cummins NTA855-G3 | 358kW Generator Engine
  • Cummins NTA855-G3 | 358kW Generator Engine
Cummins NTA855-G3 | 358kW Generator Engine Cummins NTA855-G3 | 358kW Generator Engine

Cummins NTA855-G3 | 358kW Generator Engine

  • Product Series: Cummins N855-G
  • Rated output: 358KW(480HP), 1800RPM
  • Warranty: 12 months
  • Payment: T/T, L/C, Western union, etc.
  • Lead Time: Around 15-30 Business Days
  • Cummins CCEC NTA855-G Generator Engine
    Inquiry Email Performance

    Details


    Engineering Depth and Operational Overview of the CCEC Cummins NTA855-G3 Engine

    The industrial power generation market demands absolute mechanical reliability under sustained operational loads. When facility operators and prime contractors specify a 358 kilowatt power node, the margin for error is zero. As an established industrial engine supplier, HekoPower provides fully verified CCEC Cummins NTA855-G3 power units designed specifically to meet rigorous 60Hz standby and prime power requirements. This specific model builds upon decades of heavy-duty diesel engineering, combining mechanical simplicity with high thermal efficiency.


    Tech Specs of CCEC Cummins NTA855-G3 358kW

    General Engine Data





    Engine Model: Cummins NTA855-G3
    Type: 6 Cylinders in Line, 4 Stroke Diesel
    Displacement: 14 L
    Bore * Stroke: 140 * 152
    Net Weight: 1380 Kg
    Overall Dimension: 1980mm*900mm*1600mm


    Key Performance Data





    Rated Power/Standby Output: 358 kW/480HP, 399 kW/535HP
    Torque @Rated/Standby Output: 1703/1896 N.m @ 1800 rpm
    Rated Speed: 1800 rpm
    Low Idle Speed: 575-675 rpm
    Fuel Consumption @ Rated Power: 72 L/Kw.h


    More Technical Data





    Fuel System: Cummins PT Pump, Direct Injection
    Aspiration: Turbocharged
    Electrical System (Starter Motor/Alternator): 24V/900A
    Governor Type: Mechanical Control
    Compression Ratio: 14:1
    Lowest Starting Temp (Without auxiliary system): -12℃
    Coolant Volume (Engine Only): 20.8 L
    Cooling Method: Water Cooled


    Real Application Scenarios for the NTA855-G3

    Deploying a 14-liter six-cylinder powerplant requires aligning mechanical output with specific load profiles. The NTA855-G3 is engineered primarily for stationary 1800 RPM applications operating at 60Hz.

    Primary field deployments include municipal emergency backup power systems for water treatment facilities, regional hospitals, and telecommunication data centers where uninterrupted uptime is critical. Because of its robust torque backup and stable governor response, this engine excels in continuous industrial manufacturing plants operating on prime power duty cycles. Furthermore, remote mining camps and large-scale agricultural irrigation stations frequently rely on this configuration due to its tolerance for fluctuating ambient temperatures and heavy initial electrical startup surges.


    Technical Comparisons: NTA855-G3 vs. Related Power Units

    Understanding how this model differs from neighboring variants helps engineers select the right hardware without falling into common specification traps.

    When comparing the NTA855-G3 to its predecessor, the NTA855-G2, the primary distinction lies in optimized fuel delivery calibration and turbocharger matching. While both share the same fundamental 140 mm bore and 152 mm stroke architecture, the G3 variant achieves a higher prime power output of 358 kW (480 HP) at 1800 RPM, compared to lower ratings in older iterations. This makes the G3 significantly more efficient for modern alternator head pairings that demand tighter voltage regulation and transient response.

    In contrast, when evaluating the NTA855-G3 against the larger KTA19-G3 generator engine, scale and displacement become the deciding factors. The KTA19 utilizes a 19-liter displacement platform capable of higher output tiers, but it incurs a larger physical footprint and heavier dry weight. For projects capped strictly at the 358kW to 399kW threshold, the NTA855-G3 provides an ideal balance of power-to-weight ratio, simpler component access during routine overhauls, and lower initial capital investment compared to stepping up to a 19-liter block.


    Maintenance Protocols, Replacement Tips, and Common Misconceptions

    Maximizing the operational lifespan of a heavy-duty diesel engine requires strict adherence to maintenance schedules and an understanding of its unique fuel subsystem.

    Maintaining the Cummins PT Fuel System

    The NTA855-G3 utilizes the proprietary Cummins Pressure Time (PT) fuel injection system. Unlike conventional distributor pumps, the PT system operates at high internal pressures where fuel flow timing is controlled mechanically by the injector design and gear pump pressure. Technicians must ensure ultra-fine fuel filtration to prevent particulate wear on the precision injector plungers. Regular calibration of the fuel pump rail pressure during major service intervals prevents premature smoke emissions and fuel dilution.

    Replacement and Retrofit Considerations

    When replacing an older generator drive engine with an NTA855-G3 assembly, verify flywheel housing dimensions, SAE flywheel sizing, and vibration damper clearance. While core mounting points across the N855 series remain largely standardized, variations in auxiliary cooling pack configurations and exhaust manifold orientations between older automotive conversions and dedicated G-Drive units can cause installation delays if unverified.

    Addressing Common Misconceptions

    A frequent misconception among buyers is that an engine rated for 399 kW standby power can be continuously operated at that exact ceiling without accelerated wear. Standby ratings are strictly intended for emergency utility outages with variable load profiles. For continuous or prime applications, operators must adhere to the 358 kW rating to maintain proper thermal equilibrium, exhaust gas temperatures, and scheduled oil change intervals. Another misconception is that generic aftermarket overhaul kits match OEM metallurgy; utilizing genuine CCEC components ensures thermal expansion rates match factory engineering tolerances.


    Cummins N855 Series Product Navigation

    To help you locate specific configuration variations or related replacement assemblies within the broader Cummins engine lineup, our catalog covers multiple specialized builds.

    Cummins N855-G Series, original products from Chongqing Cummins Engine Plant(CCEC). This series mainly includes NT855-G, NT855-GA, NT855-G1, NT855-G1A, NT855-G1B, NTA855-G2, NTA855-G2A, NTA855-G3, NTA855-G4, NTA855-G7, NTA855-G7A.


    Frequently Asked Questions (FAQs)

    What are the exact Cummins NTA855-G3 specifications for engine displacement?

    The engine has a total displacement of 14 liters, or 855 cubic inches, which is where the famous 855 Series designation comes from.

    What is the difference between prime power and standby power for this model?

    The NTA855-G3 is rated for a prime power output of 358 kW (480 HP) and a standby power output of 399 kW (535 HP) at 1800 RPM under standard ISO conditions. Prime power is designed for variable loads with unlimited annual operating hours, whereas standby is strictly for emergency backup.

    What makes the Cummins NTA855-G3 for diesel generator set applications so popular globally?

    Its popularity stems from the unique combination of high torque backup, ease of field maintenance, and the widespread global availability of Cummins NTA855-G3 spare parts. The engine requires roughly forty percent fewer moving parts than many competitors, drastically lowering the mechanical failure rate over a long operational life.

    Where can I find the engine identification number (CPL)?

    The Control Parts List (CPL) number for this engine configuration is typically CPL 1436, which is stamped directly on the engine data plate attached to the rocker lever cover. Providing this number to our sales team ensures absolute accuracy when sourcing replacement parts.
