Genuine Cummins ISDe270-30 Engine: The Powerhouse for 6.7L Commercial Applications
The Cummins ISDe270-30 engine is a high-performance 6.7L diesel power unit developed by Dongfeng Cummins Engine Co., Ltd. (DCEC), designed specifically for medium and heavy-duty commercial vehicles. As part of the Cummins ISDe series, this model delivers a rated output of 270HP (198kW) and is engineered to provide strong torque, fuel efficiency, and long service life.
At HekoPower, we supply original Cummins ISDe270-30 diesel engines for global customers, offering reliable solutions for truck fleet operators, distributors, and engine replacement projects. Compared with lower horsepower models such as ISDe245, the ISDe270-30 provides enhanced power output and improved load-handling capability, making it ideal for long-distance logistics and demanding road conditions.
Tech Specs of ISDe270-30 Engine
General Engine Data
Engine Model: Cummins ISDe270-30
Type: 4 Cylinders in Line
Displacement: 6.7 L
Bore * Stroke: 107 * 124
Net Weight (with flywheel & alternator): 509 Kg
Overall Dimension: 901mm*723mm*815mm
Key Performance Data
Rated Power: 198 kW/270 HP
Rated Speed: 2500 rpm
Idle Speed: 600-800 rpm
Fuel Consumption @ Rated Power: 195 g/Kw.h
Max Continuous Running Altitude: 3000 m
Max. Torque/Speed: 970 N.m @ 1200-1700 rpm
Torque/Rated Speed: 758 N.m @ 2500 rpm
Max. No-load Governed Speed: 2850 rpm
More Technical Data
Certification: Euro III/IV
Aspiration: Turbocharged & Charge Air Cooled
Fuel System: Bosch Direct Injection (HPCR)
Compression Radio: 17.3:1
Starting System: Electrical Starting Motor 24V(750A)
Lowest Starting Temp Without auxiliary system: -12℃/-25℃
Cooling Method: Water cooled
Engine Cooling Fluid Volume: 9.4 L
Key Features and Advantages of ISDe270-30 Engine
High Torque Output for Heavy-Duty Applications
The ISDe270-30 engine delivers up to 970 N·m torque, ensuring excellent pulling power for loaded trucks. This makes it particularly suitable for highway freight transport and mountainous terrain operations.
Advanced Bosch HPCR Fuel System
Equipped with a Bosch High-Pressure Common Rail (HPCR) system, the engine achieves precise fuel injection control, improving combustion efficiency and reducing fuel consumption.
Durable and Reliable Design
The Cummins ISDe270 engine is built with a robust cylinder block and optimized cooling system, ensuring long operational life and reduced maintenance frequency.
Fuel Efficiency Optimization
Compared with older mechanical diesel engines, the ISDe270-30 significantly improves fuel economy, making it a cost-effective solution for fleet operators.
Primary Applications: Beyond the Dongfeng Cummins ISDe270
While famously known as the Dongfeng Cummins ISDe270-30 truck engine, this unit's versatility extends to various platforms.
- Logistics & Heavy Trucking: The ISDe270 engine for Dongfeng commercial vehicle applications is the industry standard for reliability.
- Passenger Transport: The Cummins 270HP diesel engine for bus use provides a smooth, low-vibration experience for long-distance coaches.
- Specialty Vehicles: From concrete mixers to refuse trucks, the high power-to-weight ratio makes it a top choice for specialized machinery.
Comparison: Cummins ISDe270 vs ISDe245 and ISDe285
To avoid homogenization, it is vital to understand where the 270HP model fits in the Cummins ISDe series for sale.
270HP vs 245HP Cummins Diesel Engine
While the 245HP version is excellent for urban distribution, the ISDe270 engine for heavy truck use provides that extra 25HP margin necessary for inter-city logistics. The ISDe270 offers better acceleration under full load, reducing driver fatigue and improving turnaround times.
ISDe270 vs ISDe285 Engine Difference
The ISDe270 vs ISDe285 engine difference is subtle but important. The 270HP variant is often seen as the "sweet spot" for 15-20 ton trucks, offering nearly the same mechanical durability as the 285HP version but with a slightly more conservative tuning that can lead to a longer ISDe270 maintenance and lifespan.
Maintenance and Reliability: Is ISDe270 Reliable for Long Haul Trucks?
The short answer is yes. However, maintaining the Cummins ISDe270-30 specs torque fuel consumption requires a strict adherence to the maintenance schedule for Cummins 6.7L ISDe270-30 engine.
Genuine Parts and the Bosch HPCR System
The longevity of the ISDe270-30 HPCR diesel engine depends heavily on fuel filtration. As a wholesale original DCEC ISDe270-30 engine provider, HekoPower recommends using only genuine filters to protect the Bosch high-pressure injectors from contaminants.
HekoPower’s Commitment to Quality
When you buy ISDe270-30 diesel engine units from HekoPower, you aren't just getting an engine. Every HekoPower Cummins ISDe270-30 diesel engine undergoes a rigorous quality inspection. We provide an original ISDe270-30 diesel engine 10 business days lead time, ensuring your fleet stays on the road.
Sourcing and Availability: Wholesale Original DCEC ISDe270-30 Engine
Finding a reliable ISDe270-30 replacement engine for commercial vehicle use can be challenging. HekoPower simplifies this by offering original Cummins ISDe270-30 engine direct wholesale pricing.
Why Choose HekoPower as Your ISDe270-30 Supplier?
- Warranty: Every HekoPower Cummins ISDe270-30 engine with 12 months warranty provides peace of mind.
- Expertise: We provide a comprehensive Cummins ISDe270-30 technical specification PDF upon request to assist your technical team.
- Global Logistics: Whether you need a wholesale DCEC ISDe270-30 engine for Dongfeng truck/bus/van or a single unit for a repower project, our logistics network handles the heavy lifting.
DCEC ISDe Series, original products from Dongfeng Cummins Engine Plant (DCEC), Cummins Joint Venture Plant since 1986, 50% shareholding by Cummins USA. This series mainly includes ISDe140-30, ISDe140-40, ISDe160-30, ISDe160-40, ISDe180-30, ISDe180-40, ISDe185-30, ISDe185-40, ISDe200-30, ISDe210-30, ISDe210-40, ISDe230-30, ISDe245-30, ISDe270-30, ISDe285-30, ISDe300-40.
FAQ – Cummins ISDe270-30 Engine
Is ISDe270 reliable for long haul trucks?
Yes, the ISDe270 engine is designed for durability and consistent performance in long-distance transportation.
What vehicles use ISDe270 engine?
It is commonly used in Dongfeng trucks, buses, and other commercial vehicles.
What is the horsepower and displacement?
The engine produces 270HP with a 6.7L displacement.
